BS-112

Install essential

Compact, 12” (3” voice coil) passive subwoofer cabinet band pass configuration

Description

The BS-112 is a compact, band pass passive subwoofer cabinet designed to extend low frequency support to the four BS Series full range cabinets.

The 12” (3” voice coil) driver offers high power handling and high sensitivity with low distortion and ultra low air noise. The cone is waterproof and rubber suspension has been treated on both sides and has been optimized for direct radiation subwoofer applications.

Constructed from premium birch plywood and coated in high resistant polyurea paint. The enclosure also offers a screw free grille together with pole mount fitting so that it can be used with any of the four full range cabinets. We recommend that the cabinet presets are applied for maximum optimization and performance.

N

Perfectly suited for:

→  Club & bar installations
→  Sound reinforcement
→  Theatres
→  Houses of worship
→  Multi media spaces
→  Public address



Technical Data



Components
LF: 12” speaker, 3” ( 75 mm) copper wire voice coil, Waterproof cone with treatment on both sides
Frequency Range 40 Hz – 90 Hz with preset
Sensitivity
93 dB
Max SPL/Peak* 120 dB / 126 dB
Rated Power
500W AES (1000W program, 2000W peak)
Dispersion Quasiomnidirectional
Nominal Impedance
8 Ω
Connectors 2 X NEUTRIK Speakon NL4
Finish
Polyurea coating
Material 15 mm premium birch plywood
Dimensions
406 x 655 x 400 mm (H x W x D)
Weight 29 Kg (63.9 lbs)
Fittings
2 integrated ergonomic handles, 4 rubber feets right side for vertical install, M-10 fly points
Accessories M-10 eyebolt
Enclosure type
Band pass subwoofer

* Calculated maximum SPL based on rated peak power and measured sensitivity

More features

Hardware for BS-112

Enclosure

 This cabinet is constructed from premium birch plywood (15mm thickness) and finished with polyurea coating.

Internal design

The internal structure of the cabinet is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws.

Rear panel

Discreet, integrated rear connection speakon panel.

Grill

The cabinet has a heavy duty, powder coated front grille with a special acoustic rear fabric to protect the transducers against dust and dirt.

Handles

An ergonomic handle is located on each side of the cabinet.

Single pole mount

M20 pole support for tripod or satellite setup

Rubber feet

4 rubber feets right side for vertical install

Amplification & DSP





The BS-112 features one low frequency 12” transducer with Fiber glass ring, ferrite magnet and aluminium basket.
