RX-S15
High output, self-powered bass reflex subwoofer
High-output 15” active subwoofer, 1200W Class D, 132 dB SPL. Bass reflex design with polyurea finish, perfect for clubs and live events
Description
The RX-S15 is a high-output, self-powered subwoofer enclosure specifically designed to reinforce the low frequencies of the ROX series full-range models
The system features a 1200 W Class D amplifier with a switch-mode power supply, standing out for its exceptional power-to-size ratio
For portable applications, a wheel kit is available to facilitate transportation, and it can be protected during storage with a practical nylon sheath
Key features
|
• Class D powered |
|
• Indoor or outdoor application |
|
• Versatile sound reinforcement |
|
• High performance |
Perfectly suited for:
| → Club & bar installations |
| → Live events |
Technical Data
Components |
LF: 1 x 15”, 4” voice coil |
| Frequency Range | 40 Hz – 300 Hz (-10dB) Adjustable |
| Frequency response | 45 Hz – 250 Hz (- 3dB) Adjustable |
Max SPL |
126 dB – 132 dB peak* |
| Coverage | Omnidirectional |
| Input / Output | Balanced XLR input / output |
| Power | 1200W Class D with switching power supply |
| Processing | Analogue |
| Control | User control interface |
| AC Power | 90 – 260V. 50/60 Hz |
| AC Connectors | 16A powercon with looping output |
| Fittings | M20 Pole Insertion |
| Finish | Polyurea coating, high grade resistant paint |
| Material | 15 mm Premium plywood |
| Dimensions | 500 x 450 x 572 mm (H x W x D) |
| Weight | 33 Kg (72.75 lbs) |
* Calculated maximum SPL based on rated peak power and measured sensitivity
