HR 1264/7 & HR 1296/7

Pure install speaker

High performance, ultra-compact, full range, two way bi-amp/ passive cabinet.

Description

High performance, ultra-compact, full range, two way bi-amp/passive cabinet. It consists of a 12” transducer and a 1.4” high frequency compression driver.

They offer 2 dispersion options. The model HR-1264/7 provides a narrow dispersion of 60º x 40º (rotatable) and the model HR-1296/7 offers a wide dispersion of 90º x 60º (rotatable). 129dB SPL (1400W program).

This cabinet is ideal for a wide variety of applications and has a range of accessories that facilitate its assembly. Although this cabinet can be used without a processor, we strongly recommend that the cabinet presets are applied for maximum optimization and performance.

For Low Frequency reinforcement, several subwoofer options are available.

N

Perfectly suited for:

→  Club & Bar installations
→  Sound reinforcement
→  Theatres
→  Houses of worship
→  Conferences
→  Public address

Technical Data

Components
LF: 12″. 3.5″ aluminium voice coil, waterproof front side cone treatment, neodymium magnet
HF: 1.4″ Exit compression Driver, 2.5″ aluminium voice coil, Titanium diaphragm
Frequency Range 59 Hz – 20 KHz (-10dB)
Frequency Response
65 Hz – 18 KHz (± 3dB)
Sensitivity Passive Mode: 94 dB (1W@1m)
Max SPL
Passive Mode: 123dB – 129dB Peak
Bi-Amp LF: 125dB – 131dB Peak
Bi-Amp HF: 127dB – 133dB Peak
Coverage

Constant directivity horn (Rotatable)

90º x 60º (HR-1296/7) / 60º x 40º (HR-1264/7)

Power
Passive mode: 700 W (1400 W program, 2800 W peak)
Bi- Amp LF: 700 W (1400 W program, 2800 W peak)
Bi-Amp HF: 80 W (160 W program, 320W peak)
Crossover Bi-Amp / Passive (Selectable)
Nominal Impedance
Ω Passive / Bi-amp LF 8 Ω, HF 8 Ω
Connectors 2 x Neutrik Speakon NL4MP
Finish
Polyurea coating – other colours (RAL) available
Material 15 mm premium birch plywood
Dimensions
705 x 377 x 495 mm (H x W x D)
Weight 26 Kg (57 lbs)

More features

Hardware for HR-1264/7 & HR-1296/7
Enclousure-v12
Enclosure

The HR-1264/7 & HR-1296/7 cabinet is constructed from 11-ply premium birch plywood (15mm thickness) and finished with polyurea coating.

Internal design

The internal structure of the HR-1264/7 & HR-1296/7 is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws.

Rear-panel-HR-15
Rear panel

A compact powder coated steel panel contains the NL4MP connectors.

Grill HR-12
Grill

The HR-1264/7 & HR-1296/7 has a heavy duty, powder coated front grille with a special acoustic rear fabric to protect the transducers against dust and dirt.

Handle HR-15
Handles

An ergonomic handle is located on the rear panel of the enclosure to facilitate transport, positioning and loading of the cabinets.

Rigging HR-15
Rigging

A heavy duty track is integrated on the top of the enclosure to facilitate its installation.

Accessories for HR-1264/7 & HR-1296/7
AGR-10 AGR-10
Eye bolt for HR 1264/7 & HR 1296/7 cabinets
SC-FC1 SC-FC1
Lightweight install stud for HR 1264/7 & HR 1296/7

SC-FC2

SC-FC2
Heavyweight install stud for HR 1264/7 & HR 1296/7
CS-HR1215
Cluster support for HR 1264/7 & HR 1296/7 cabinets

UBR-HR12

Horizontal U bracket for HR 1264/7 & HR 1296/7 cabinets

WB-30

Wall bracket for HR 1264/7 & HR 1296/7 cabinets

Konig & meyer 195/8 mouting adapter compatibility NOTE: This cabinet is compatible with Konig & Meyer 195/8 mounting adapter for speaker stands with 35 mm tube diameter. This accessory is not provided by Lynx Pro Audio.
Weather-resistant version

Our weather-resistant version speakers are designed to withstand harder weather conditions, where the cabinets are exposed to the elements.

Colours:

  • Black polyurea coating with microtextured metal parts.
  • RAL available on request. Polyurea coating with aliphatic colour paint.

1. Anodized aluminium logo for durability outdoors.

2. Stainless steel 1 mm 316 L grill. Also available in aluminum with protective layer and micro textured paint.

3. Weatherstrip edging for extreme protection.

4. Acoustex filter: hydrophobic polyester sheet to prevent the penetration of water and external elements produced by extreme weather conditions.

5. 35 ppi Acoustic foam to protect against dust particles.

6. Waterproof protected cone on both sides

7. Aluminum back plate with pressure gland for an extra tight connection and easy installation.

8. M10 stainless steel 316 L screws (A4).

1 x 6” transducer, 116 dB SPL

Weather-resistant version available

1 x 8” transducer, 122 dB SPL

Weather-resistant version available

2 x 4” transducers with 1 x 1″ tweeter , 118 dB SPL

Weather-resistant version available

2 x 6.5” transducers with 1 x 1″ driver , 117 dB SPL

Weather-resistant version available

2 x 8” transducers with 1 x 1” driver, 120 dB SPL

Weather-resistant version available

1 x 12” transducer with 1 x 1.4″ driver, 121 dB SPL

Weather-resistant version available

1 x 15” transducer with 1 x 1.4” driver, 123 dB SPL

Weather-resistant version available

1 x 15” transducer with 1 x 1.4” driver, 123 dB SPL

Weather-resistant version available

2 x 18” transducers, 139 dB SPL

Weather-resistant version available

2 x 18” transducers, 136 dB SPL

Weather-resistant version available

2 x 15” transducer, 133 dB SPL

Weather-resistant version available

1 x 18” transducer, 129 dB SPL

Weather-resistant version available
