HR-1564/5 & HR-1596/5

Pure install speaker

High performance, ultra-compact, full range, two way bi-amp/ passive cabinet.


High performance, ultra-compact, full range, two way bi-amp/passive cabinet.
It consists of a 15”transducer and a 1”high frequency compression driver.

They offer 2 dispersion options. The model HR-1564/5 provides a narrow dispersion of 60º x 40º (rotatable) and the model HR-1596/5 offers a wide dispersion of 90º x 60º (rotatable). 129dB SPL (1000W program).

This enclosure is ideal for a wide variety of applications and has a range of accessories that provide an easier assembly. Although this cabinet can be used without a processor, we strongly recommend that the cabinet presets are applied for maximum optimization and performance.

For Low Frequency reinforcement, several subwoofer options are available.


Perfectly suited for:

→  Club & Bar installations
→  Sound reinforcement
→  Theatres
→  Houses of worship
→  Conferences
→  Public Address

Technical Data

LF: 15″, 2.5″ voice coil, Malt Cross Cooling System
HF: 1,4″ Exit compression Driver, 1.75″ aluminium voice coil
Frequency Range58 Hz – 20 KHz (-10dB)
Frequency Response
63 Hz – 18 KHz (± 3dB)
SensitivityPassive Mode: 96dB (1W@1m)
Passive Mode: 123dB – 129dB Peak
Bi-Amp LF: 125dB – 131dB Peak
Bi-Amp HF: 126dB – 132dB Peak
CoverageConstant directivity horn (Rotatable)
90º x 60º (HR-1596/5) / 60º x 40º (HR-1564/5)
Passive mode: 500 W (1000 W program, 2000 W peak)
Bi- Amp LF: 500 W (1000 W program, 2000 W peak)
Bi-Amp HF: 60 W (120 W program, 240W peak)
CrossoverBi-Amp / Passive (Selectable)
Nominal Impedance
Ω Passive / Biamp LF 8 Ω, HF 8 Ω
Connectors2 x Neutrik Speakon NL4MP
Polyurea coating – other colours (RAL) available
Material15 mm premium birch plywood
790 x 444,5 x 541 mm (H x W x D)
Weight30 Kg (66 lbs)

More features

Hardware for HR-1564/5 & HR-1596/5

The HR-1564/5 & HR-1596/5 cabinet is constructed from 11-ply premium birch plywood (15mm thickness) and finished with polyurea coating.

Internal design

The internal structure of the HR-1564/5 & HR-1596/5 is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws.

Rear panel

A compact powder coated steel panel contains the connectors.

Grill HR-15

The cabinet has a heavy duty, powder coated front grille with a special acoustic rear fabric to protect the transducers against dust and dirt.

Handle HR-15

An ergonomic handle is located on the rear panel of the enclosure to facilitate transport, positioning and loading of the cabinets.

Rigging GXR-215

Three fixing points are integrated on the top of the enclosure to facilitate its installation.



Accessories for HR-1564/5 & HR-1596/5
Eye bolt for HR 1564/5 & HR 1596/5 cabinets
Cluster support for HR 1564/5 & HR 1596/5 cabinets
Marine Grade Option

This cabinet is also available for Marine environments, such as cruise ships for example.

Our Marine option speakers are designed to withstand harder weather conditions, where the cabinets are exposed to the elements.


  • Black polyurea coating with microtextured metal parts.
  • RAL available on request. Polyurea coating with aliphatic colour paint.

1. Anodized aluminium logo for durability outdoors.

2. Stainless steel 1 mm 316 L grill. Also available in aluminum with protective layer and micro textured paint.

3. Weatherstrip edging for extreme protection.

4. Acoustex filter: hydrophobic polyester sheet to prevent the penetration of water and external elements produced by extreme weather conditions.

5. 35 ppi Acoustic foam to protect against dust particles.

6. Waterproof protected cone on both sides

7. Aluminum back plate with pressure gland for an extra tight connection and easy installation.

8. M10 stainless steel 316 L screws (A4).
