HR-215S

Pure install subwoofer

High power, ultra compact, subwoofer cabinet with two 15” low frequency transducers with rubber suspension in triple band-pass configuration. 139dB Peak (4000W program)

Description

The HR-215S is a high-performance compact subwoofer designed to work with the HR range full range cabinets, offering impressive low-frequency reinforcement with an excellent power-volume-to-weight ratio.

High power, ultra compact,sub-bass cabinet with two 15” low frequency transducers with rubber suspension in triple band-pass configuration. 139dB Peak (4000W program).

N

Perfectly suited for:

→  Club & Bar installations
→  Sound reinforcement
→  Theatres
→  Houses of worship
→  Multi media spaces
→  Public address

Technical Data

Components
LF: 2 x 15′′ transducers
Frequency Range30 Hz – 160 Hz (-10dB)
Frequency Response
35 Hz – 150 Hz (± 3dB)
Sensitivity100 dB (1W@1m) π
Max SPL
133 dB – 139 dB Peak
CoverageQuasi Omnidirectional
Power
2000 W (4000 W program, 8000 W peak)
CrossoverActive
Nominal Impedance
Ω
Connectors2 x Neutrik Speakon NL4MP
Finish
Polyurea coating – other colours (RAL) available
Material18 mm premium birch plywood
Dimensions
644 x 463 x 600 mm (H x W x D)
Weight59 Kg (130 lbs)

More features

Hardware for HR-215S



Enclousure-ADP
Enclosure

The HR-215S cabinet is constructed from 13-ply premium birch plywood (18mm thickness) and finished with polyurea coating.

Internal design

The internal structure of the HR-215S is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws.

Rigging HR-18-6
Rear panel

A compact powder coated steel panel contains the connectors.

Handle-HR-215S
Handles

An ergonomic handle is located on each side of the HR-215S enclosure to facilitate transport, positioning and loading of the cabinets.



Weather-resistant version

Our weather-resistant version speakers are designed to withstand harder weather conditions, where the cabinets are exposed to the elements.

Colours:

  • Black polyurea coating with microtextured metal parts.
  • RAL available on request. Polyurea coating with aliphatic colour paint.

1. Anodized aluminium logo for durability outdoors.

2. Stainless steel 1 mm 316 L grill. Also available in aluminum with protective layer and micro textured paint.

3. Weatherstrip edging for extreme protection.

4. Acoustex filter: hydrophobic polyester sheet to prevent the penetration of water and external elements produced by extreme weather conditions.

5. 35 ppi Acoustic foam to protect against dust particles.

6. Waterproof protected cone on both sides

7. Aluminum back plate with pressure gland for an extra tight connection and easy installation.

8. M10 stainless steel 316 L screws (A4).

Accessories for HR-215S

TU-C01
TU-C01
35mm connecting pole for satellite combination between HR-215S and HR full range cabinets
TU-C02
TU-C02
M20 pole support combination between HR-215S and HR full range cabinets. With safety lock
VSM-V1
VSM-V1
35mm speaker mounting top hat for satellite combination between HR-215S and HR full range cabinets
VSM-V2
VSM-V2
M20 connector plate for the HR-215S

1 x 6” transducer, 116 dB SPL

Weather-resistant version available

1 x 8” transducer, 122 dB SPL

Weather-resistant version available

2 x 4” transducers with 1 x 1″ tweeter , 118 dB SPL

Weather-resistant version available

2 x 6.5” transducers with 1 x 1″ driver , 117 dB SPL

Weather-resistant version available

2 x 8” transducers with 1 x 1” driver, 120 dB SPL

Weather-resistant version available

1 x 12” transducer with 1 x 1.4″ driver, 121 dB SPL

Weather-resistant version available

1 x 12” transducer with 1.4″ driver, 123 dB SPL

Weather-resistant version available

1 x 15” transducer with 1 x 1.4” driver, 123 dB SPL

Weather-resistant version available

1 x 15” transducer with 1 x 1.4” driver, 123 dB SPL

Weather-resistant version available

2 x 18” transducers, 139 dB SPL

Weather-resistant version available

2 x 18” transducers, 136 dB SPL

Weather-resistant version available

1 x 18” transducer, 129 dB SPL

Weather-resistant version available
