RX-S18

High output, self-powered bass reflex subwoofer

High output, self powered 1200 W (class D switch mode power supply), bass reflex direct radiation subwoofer cabinet. 128 dB SPL.

The RX-S18 enclosure is a self-powered subwoofer enclosure specially designed to reinforce the low frequencies of the full range models of the ROX series. You do not need to carry an external amplification rack and it is an excellent option for subwoofer reinforcement in general.

The enclosure has 1200 W class D amplifier switching power supply. This system can be controlled in real time and stands out for its high performance, with an excellent power-size ratio. For portable applications, a wheel kit is available to facilitate transportation. It can also be covered with a practical nylon sheath that protects the box during transport and storage.

Perfectly suited for:

Club & bar installations
Live events

• Class D powered
• Indoor or outdoor application
• Versatile sound reinforcement
• High performance

Components

LF: 1 x 18”, 4” voice coil

Frequency Range

40 Hz – 300 Hz (-10dB) Adjustable

Frequency Response

35 Hz – 250 Hz (± 3dB) Adjustable

Max SPL*

128 dB – 134 dB Peak

Coverage

Omnidirectional

Input/Output

Balanced XLR input / output

Power

1200W Class D with switching power supply

Processing

Analogue

Control

User control interface

Fittings

M20 Pole Insertion

AC Power

90 – 260V. 50/60 Hz

AC Connectors

16A powercon with looping output

Finish

Polyurea coating, high grade resistant paint

Material

15 mm Premium plywood

Dimensions

542 x 560 x 780 mm (H x W x D)

Weight

42 Kg (92.59 lbs)

More features

Hardware for RX-S18

Enclosure

The RX-S18 cabinet is constructed from 15 mm premium plywood and finished with polyurea coating.

Internal design

The internal structure of the RX-S18 is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws. The amplification modules & DSP are housed in a separate chamber to the drivers avoiding excessive heat & vibration, thus delivering greater efficiency and reliability.

Real panel

The powder coated steel rear panel contains all connections and houses the RX-S18 amplification modules and DSP, is easily accessible and housed separately from the drivers for increased reliability and efficiency.
