Ionic V28

Smart & slim column speaker

Compact, passive two-way column speaker. Consists of 8 x 4″ speakers and 1″ high frequency driver on waveguide designed for fixed installations.

The Ionic-V28 is a two-way passive column speaker part of the Ionic series. This column is oriented to contain high fidelity voice and has more vertical directivity thanks to the waveguide.

It is the newest and most powerful column system in the series and it is ideal for indoor installations, conference rooms, houses of worship and sound reinforcement.

It can be powered from the subwoofer units which include a Digital Signal Processor offering different presets to cover a wide range of sound applications. It can also be powered from an external amplifier.

Although this cabinet can be used without a processor, the best performance is achieved when using our presets, optimised for LUKA processors and GTX amplifiers. Please note that using the cabinet without our recommended processors or amplifiers may affect the product warranty.

Perfectly suited for:

  • PA system
  • Clubs & Theatres
  • Houses of Worship
  • Conference rooms
  • Public buildings
  • Commercial complex
  • Sound reinforcement
  • Passive Performance: Two-way column speaker rated at 560 W, 1120 W program and 2240 W peak.
  • Components: Eight 4″ LF/MF speakers with 1″ voice coils and an HF driver with a 1″ exit on a waveguide.
  • Acoustics: 126 dB maximum SPL / 132 dB peak; processed frequency range of 80 Hz–20 kHz (-6 dB).
  • Coverage: 100° H × 25° V dispersion.
  • Construction: 9 and 15 mm birch plywood, finished with water-based paint.
  • Connectivity: Neutrik NL4MP and 4-pole PHOENIX connectors. Powered by compatible Ionic subwoofer units or an external amplifier.
Components
  • Low/mid: 8 x 4″ speakers with 1″ voice coil
  • High: 1 x 1″ exit on waveguide
Frequency Range

80 Hz – 20 KHz (-6dB) processed

Sensitivity

99 dB (1W@1m)

Max SPL

126 dB – 132 dB Peak

Coverage

100º H x 25º V

Power

560 W (1120 W program, 2240 W peak)

Nominal Impedance

8 Ω

Connectors

1 x Neutrik NL4MP / 4 poles PHOENIX connector

Finish

Water-based paint

Material

9 y 15 mm birch plywood

Dimensions

1004 x 118 x 149 mm (H x W x D)

Weight

12 Kg (26.4 lbs)

More features

Hardware for Ionic V28

SV-23

Piece to connect Ionic columns to wall or truss bracket

SV-POLE

35mm inclinable Pole adaptor

WB-I20/2

Wall bracket for column installation – inclinable
