KR-12

Club system for KTV and karaoke rooms

Compact, two-way passive cabinet. Consists of a 12” (3” voice coil) LF transducer and a 1” HF driver mounted on a 90º x 60º rotatable horn.

The KR-12 is a compact, passive two-way enclosure for fixed installations. It combines a 12″ LF speaker with a 3″ copper voice coil and a cone waterproof-treated on both sides, and a BMS HF driver with a 1″ exit, 38 mm voice coil and annular diaphragm.

Its 90° × 60° rotatable horn allows coverage to be adapted to the mounting orientation. Designed particularly for clubs, KTV and karaoke rooms, it is also suitable for houses of worship, multimedia spaces and public address.

The 15 mm MDF cabinet has a high-resistance polyurea finish, a screwless grille with protective acoustic fabric, concealed Speakon connections and an ergonomic rear handle. Dedicated mounting accessories support different installation options.

Although the enclosure can be used without a processor, we recommend our presets, optimised for LUKA processors and GTX amplifiers. Using the enclosure without our recommended processors or amplifiers may affect the product warranty.

Perfectly suited for:

  • Clubs & Bar installations
  • KTV & Karaoke rooms
  • Houses of worship
  • Public address
  • Multi media spaces
  • Sound reinforcement
  • Designed for fixed installations, particularly clubs, KTV and karaoke rooms.
  • A 90° × 60° rotatable horn adapts coverage to the mounting orientation.
  • The 12″ LF speaker has a cone waterproof-treated on both sides.
  • A BMS HF driver with an annular diaphragm handles high-frequency reproduction.
  • The MDF cabinet has a durable polyurea finish and a screwless grille with protective acoustic fabric.
  • Concealed Speakon connections, a rear handle and dedicated mounting accessories complete the enclosure.
Components
  • LF: 12” speaker, 3” (75 mm) copper wire voice coil, waterproof cone with treatment on both sides
  • HF: 1” exit throat (38 mm) voice coil, BMS annular diaphgram driver
Frequency Range

58 Hz – 22 KHz (-10dB)

Sensitivity

97 dB

Max SPL/Peak

124 dB / 130 dB peak

Rated Power

500W AES (1000W program, 2000W peak)

Coverage

90º x 60º rotatable

Nominal Impedance

8 Ω

Connectors

2 x Neutrik Speakon NL4MP

Finish

Polyurea coating

Material

15 mm premium MDF

Dimensions

600 x 363 x 410 mm (H x W x D)

Weight

24 Kg (52.9 lbs)

Fittings

14 x M8, ergonomic handle on the back position, 4 x M6 U-bracket, 4 x M6 wall bracket, 35 mm top hat

More features

Hardware for KR-12

AGR-8

M8 Eyebolt

WB-20/3

Wall bracket for KR-12

UBR-KR12

U bracket for KR-12
