Ionic V28

Smart & slim column speaker

Compact, passive two-way column speaker. Consists of 8 x 4″ speakers and 1″ high frequency driver on waveguide designed for fixed installations. 138.5 dB SPL (1120 W program).

Description

The Ionic-V28 is a two-way passive column speaker part of the Ionic series. This column is oriented to contain high fidelity voice and has more vertical directivity thanks to the waveguide.

It is the newest and most powerful column system in the series and it is ideal for indoor installations, conference rooms, houses of worship and sound reinforcement

It can be powered from the subwoofer units which include a Digital Signal Processor offering different presets to cover a wide range of sound applications. It can also be powered from an external amplifier.

N

Perfectly suited for:

→  PA system
→  Clubs & Theatres
→  Houses of Worship
→  Conference rooms
→  Public buildings
→  Commercial complex
→  Sound reinforcement

Technical Data

Components
Low/mid: 8 x 4″ speakers with 1″ voice coil
High: 1 x 1″ exit on waveguide
Frequency Range80 Hz – 20 KHz (-6dB) processed
Sensitivity*99 dB (1W@1m)
Max SPL**
126 dB – 132 dB Peak
Coverage100º H x 25º V
Power
560 W (1120 W program, 2240 W peak)
Nominal Impedance8 Ω
Connectors
2 x Neutrik NL4MP / 4 poles PHOENIX connector
FinishWater-based paint
Material
9 y 15 mm birch plywood
Dimensions1004 x 118 x 149 mm (H x W x D)
Weight
12 Kg (26.4 lbs)

* 2,83v@1m Pink noise with 12dB crest factor processed.

** Calculated based on power rating and measured sensitivity processed.

More features

Accessories for Ionic-V28
SV-23
SV-23
Piece to connect columns to wall or truss
SV-POLE
SV-POLE
35mm inclinable Pole adaptor
WB-I20/2
Wall bracket for column installation – inclinable

Other products from this series

12 x 3” transducers, 121 dB SPL

4 x 4” transducers, 129 dB SPL

6 x 3” transducers, 119 dB SPL

1 x 5” transducers, 120 dB SPL

1 x 12” transducer, 127 dB SPL

1 x 18” transducer, 132 dB SPL
