Outdoor installation at Hotel Playa Golf, Mallorca

Outdoor installation at Hotel Playa Golf, Mallorca

Designing a reliable sound system for hotel exteriors requires more than just placing weatherproof speakers around a terrace. It involves understanding the real acoustic and operational needs of each area: how the space is used, how sound behaves in open-air environments, and how to ensure consistent performance over time.

At Hotel Playa Golf, a four-star resort facing Playa de Palma, one of Mallorca’s busiest coastal destinations the challenge was clear. With constant outdoor activity during high season and full exposure to sun, humidity, and salty air, this project called for an audio solution tailored for durability, coverage, and seamless integration into the architecture and daily operation of the hotel.

Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio

Installing a professional outdoor audio system in a hospitality environment like this means accounting for multiple uses: background music, events, and live sessions, all in open areas with little acoustic control. Standard sound systems aren’t designed for this level of demand. That’s why equipment selection, layout, and signal processing in this project followed strict technical criteria.

To provide background music across pool areas, terraces, and walkways, JUNO-8T loudspeakers were installed. These compact 8” passive speakers include a 100 V line transformer for low-impedance distribution and deliver a 90° x 50° dispersion, 92 dB sensitivity (1 W/1 m). Designed for permanent use outdoors, they feature a treated plywood enclosure, polyurea coating, and IP46-rated weather protection.

Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio
Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio

In spaces that demand higher SPL, such as event zones or areas with amplified content, HR-208 loudspeakers were added. These passive two-way speakers include an 8” woofer and a 1” compression driver on a constant directivity horn, offering 96 dB sensitivity and 400 W AES power handling. Their polyurea-coated enclosures and corrosion-resistant steel grilles ensure durability even in harsh weather.

Sub-bass reinforcement is handled by HR-18/10 subwoofers. This high-performance subwoofer features an 18″ driver with a 3″ copper voice coil, delivering a frequency response of 46 Hz to 200 Hz (±3 dB) and a sensitivity of 101 dB (1W@1m). Capable of producing a maximum SPL of 135 dB peak, it operates with 1000 W RMS (4000 W peak) power handling. Designed for omnidirectional coverage, it includes an active crossover and 8 Ω nominal impedance.

Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio

System-wide amplification and control are managed via MH Series amplifiers, which offer zone-specific setup, onboard EQ, RMS limiting, and thermal protection. By integrating amplification and DSP in a single unit, the system becomes easier to install and maintain, while ensuring reliable long-term operation.

Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio
Hotel playa Golf Mallorca. Instalación de audio Lynx Pro Audio

The project at Hotel Playa Golf illustrates how a properly specified outdoor speaker system, using dedicated hardware for weather resistance, coverage, and control, can deliver high-quality sound across a variety of uses. In environments with constant exposure and high guest turnover, system design must be grounded in experience, precision, and the right tools for the job.

Outdoor sound systems for beach clubs and terraces

Outdoor sound systems for beach clubs and terraces

During the summer season, venues such as beach clubs, terraces, rooftops or outdoor dining areas require outdoor sound systems specifically designed to operate in demanding conditions. Good-response loudspeakers are not enough: the system must operate stably for hours, with direct exposure to the sun, salt spray, high humidity and sudden temperature changes. In these environments, an installation must be unobtrusive, robust and capable of providing uniform coverage without compromising durability or sound quality.

Professional loudspeakers with weather-resistant version must be constructed of materials resistant to moisture, dust and corrosion. But in addition to physical sealing, it is critical that the acoustic design be optimized for outdoor environments: with controlled directivity, good midrange sensitivity, and performance stability at moderate levels over long days. Lynx Pro Audio offers a number of weather-certified solutions, including the JUNO, HR (MG version) or WCX series all with variants prepared for direct exposure.

JUNO Series: Compact and discreet outdoor sound

The JUNO series represents a compact, discreet and highly efficient solution for fixed outdoor installations. Available in 6 “and 8” models, JUNO combines a lightweight construction with IP46 certification, high-strength polyurea finish and transducers selected for their thermal stability and mechanical resistance. This type of system makes it ideal for restaurant terraces, chill-out areas and installations where visual integration is key.

Juno miniature commercial audio

Installations in terraces, rooftops, and hospitality venues require loudspeakers capable of delivering high sound pressure levels with consistent performance in challenging outdoor environments. The HR series in its Marine Grade (MG) version is specifically designed to meet these demands.

HR MG Series: High performance and Marine-Grade resistance

Solutions such as the HR-218/36 MG subwoofer and the full-range HR-1264/5 MG and HR-1296/5 MG models deliver powerful, high-fidelity sound, making them ideal for long-term outdoor installations where both audio performance and durability are critical.

A common practice in real-world installations is to combine both series. In the Lawn Beach Bar in Bali, for example, JUNO and WCX loudspeakers were used for the wide and discreet coverage areas, complemented by HR MG series subwoofers, thus achieving a balanced system with excellent response across the entire spectrum and without compromising weather resistance.

Another example is the Marina Beach Club in Valencia or the Sundays Beach Club in Bali, where JUNO, WCX and HR loudspeaker systems have been installed, intelligently combining acoustic performance, visual integration and structural strength. These projects demonstrate that with the right technical approach it is possible to maintain consistent sound quality even in demanding environments.

In installations with outdoor sound systems, the acoustic design must be accompanied by a strategic placement of the emission points. The use of a distributed system not only improves the homogeneity of the coverage, but also reduces the disturbance to the environment. The orientation should be aligned with the listening plane, avoiding projecting sound onto reflective surfaces such as glass facades or hard floors. Structurally, the use of specific stainless steel or anodized aluminum hardware is essential to ensure stability against wind, vibration or corrosion.

Operational control and system management

Finally, there is the issue of operational control. In most of these spaces there is no resident technician, so system management must be simple, secure and automatable. The LUKA digital processors allow you to configure the system by zones, set volume limits, apply equalization curves and program on/off schedules. This ensures smooth operation, reduces the risk of overload and keeps the system running reliably throughout opening hours.

Each outdoor sound system project presents unique conditions: from the architecture of the space and the type of use, to the user profile and environmental exposure. There is no standard solution, but there are fundamental principles that apply in each case: the use of systems specifically designed for outdoor environments, a rigorous acoustic design based on technical criteria, and the implementation of high-strength materials that guarantee durability.

Lynx Pro Audio sounds Park Shanghai in Pakuwon

Lynx Pro Audio sounds Park Shanghai in Pakuwon

JUNO Series installation at Park Shanghai



The JUNO series by Lynx Pro Audio was selected as the sound solution for Park Shanghai , the new themed outdoor area at Pakuwon City Mall in Surabaya, Indonesia. A total of 14 audio points have been installed, carefully distributed to provide uniform sound coverage throughout the venue while preserving its architectural integrity.

Weather resistance and outdoor design



The choice of the JUNO series was primarily driven by its exceptional weather resistance. Specifically designed for outdoor use, these loudspeakers feature robust construction, waterproof materials, and components engineered to withstand adverse environmental conditions such as humidity, extreme heat, and prolonged sun exposure. These attributes make them an ideal solution for permanent installations in open spaces that require reliable, uninterrupted performance.

Juno series by Lynx Pro Audio Shangai park city mall
Shanghai park pakuwon city mall by Lynx Pro Audio

A themed environment combining culture and recreation



Park Shanghai spans approximately 2 hectares of landscaped areas, pedestrian paths, and architecture inspired by traditional Chinese cities. It is a dynamic environment that combines gastronomy, cultural programming, and recreational activities, drawing thousands of visitors daily. Its oriental design, featuring pagodas, lanterns, and ceremonial gates, required a discreet yet effective technical integration that would not disrupt the visual harmony of the space.

Discreet and effective technical integration


Thanks to their compact and elegant design, the JUNO loudspeakers fit seamlessly into the venue, ensuring high-quality sound while maintaining a low visual impact. The result is a professional outdoor sound system that enhances the visitor experience without compromising the aesthetic of the park.

The installation was carried out by Melodia, an experienced systems integrator for commercial and public environments. Thanks to careful technical execution, a functional and durable solution was achieved, adapted to the needs of the project.

Audio Installation at Le Pélican Yacht Club, Beirut

Audio Installation at Le Pélican Yacht Club, Beirut

Located along Beirut’s marina, Le Pélican Yacht Club is a carefully curated venue that merges minimalist design with warm Mediterranean character. Conceived by architect Antoine Maalouf, the space reflects a consistent architectural language open: layouts, natural materials, and soft visual continuity throughout. Every design element, from finishes to lighting, contributes to a quiet elegance where function and form are equally prioritized.

Your content goes here. Edit or remove this text inline or in the module Content settings. You can also style every aspect of this content in the module Design settings and even apply custom CSS to this text in the module Advanced settings.

Le Pélican Yacht Club

A space where design and function meet

In such an environment, sound integration is more than a technical requirement: it is about preserving visual harmony while providing a clear and uniform sound. The room needed a system capable of maintaining acoustic coherence without altering the architectural intent. To achieve this, Eltek, our renowned distributor in Lebanon, installed eight Lynx Pro Audio BS-8 loudspeakers were installed in the main interior areas.

Lynx Pro Audio BS-8: Compact and accurate

The BS-8 is a compact passive full-range speaker designed for indoor fixed installations, especially in venues that demand both acoustic accuracy and visual subtlety. Each unit features an 8” low-frequency driver and a 1” compression driver mounted on a 90° x 60° constant directivity horn. With a sensitivity of 93 dB, the BS-8 provides sufficient output with a limited number of sources ideal for reducing hardware visibility in architecturally sensitive settings.

In this installation, all units were mounted at ceiling level using discreet brackets, allowing the system to blend seamlessly into the architectural framework without drawing visual attention. As a trusted expert audio-solution provider, Eltek has crafted a system that stays practically invisible while delivering natural, intelligible coverage throughout the dining areas.

A balanced audio solution for elegant interiors

Eltek’s installation at Le Pélican Yacht Club demonstrates how a system built around clear acoustic planning and appropriate loudspeaker selection such as the BS-8 by Lynx Pro Audio can deliver a high level of performance without compromising architectural integrity. It is a model of how professional audio systems can be applied with restraint and precision in design-driven environments.

Le Pélican Yacht Club
Lynx Pro Audio at the FIA Motorsport Games 2024

Lynx Pro Audio at the FIA Motorsport Games 2024

The 2024 FIA Motorsport Games, held at Valencia’s iconic City of Arts and Sciences, were a spectacle of talent, competition and energy. Nearly 800 athletes representing 86 countries at this amazing event. Lynx Pro Audio rose to the challenge, providing exceptional audio coverage with our renowned CLS Series.

Sound system configuration: CLS-212 y CLS-218s

For this large-scale event, we strategically chose the CLS Series for the main system. This comprised 4 clusters of 8 CLS-212 speakers alongside 16 CLS-218S subwoofers. This configuration was chosen to uniformly and accurately cover the entire venue, achieving powerful and balanced sound that adapted to the acoustics of an open space.

  • CLS-212: This three-way line array system excels at projecting sound over long distances with controlled dispersion, making it ideal for large events. Its compact design allows for efficient rigging without compromising on performance or coverage.



  • CLS-218S: The 18” subwoofers deliver extended low-frequency response, adding depth and richness to the sound system. The CLS-218S can handle high sound pressure levels without distortion, providing a presence in the lower frequencies.

Side fill system: CLS-28 for extended coverage

To ensure that sound reached all areas of the venue, 2 clusters of 6 CLS-28 speakers were deployed as a side fill system. This ensured consistent audio quality across the venue, reaching even the most peripheral areas.

The CLS-28, a two-way line array system, is designed for faithful reproduction of mid and high frequencies, making it an ideal choice for side fill in large-scale events. It design allowed for a smooth integration with the main setup, ensuring balanced sound throught the event.

Montaje Fia CAC, backstage

Monitoring system: ADP-212M for live stages

For monitoring, 8 ADP-212M monitors were set up to provide clear feedback for presenters and artists during the ceremony.

The ADP-212M is an active two-way monitor that provides exceptional clarity for live stage applications. With controlled response over mid and high frequency ranges, it allowed presenters and performers to hear themselves with precision.

The sound of Lynx Pro Audio’s at FIA Motorsport Games 2024 was an excellent opportunity to demonstrate the capabilities and versatility of our equipment at a large-scale event held in an acoustically challenging venue. The precision, clarity and power of our audio systems enabled us to meet the high demands of the organisers and the public, creating a sound environment worthy of this international ceremony.
